HDPE Electrofusion Fittings

Home > Product > Electrofusion Fittings > HDPE Electrofusion Fittings

HDPE Electrofusion Fittings

Share This Product:

Items	HDPE Electrofusion Fittings
Material	Polyethylene
Size	20-315mm
Color	Black
Connection	Electro fusion
Pressure	1.25MPa,1.6MPa,2.0MPa,2.5MPa
Standard	DIN8077, DIN8078 ,ISO15874
Certification	ISO14001,OHSAS18001,ISO9001,CE,GOST，DVGW

Highlights of HDPE Electrofusion Fitting Products:

1. Stronger connection, suitable for high-pressure water delivery systems,Through electric fusion welding, it has high welding strength and excellent sealing performance, and is widely used in municipal water supply, gas and mining transportation systems.
Compatible with various specifications of HDPE pipes

We can provide a full range of specifications of HDPE electro fusion fittings from 20mm to 1000mm, suitable for installation in various scenarios.

or
Advantages

Corrosion resistance, aging resistance, service life of more than 50 years,Using high-quality PE100 raw materials, it has excellent chemical stability and is suitable for underground, humid, and corrosive environments.

Quick and convenient installation, supporting automatic welding machine operation,All products comply with ISO and EN standards, are compatible with mainstream electric fusion welding machines, and achieve efficient construction.

Features

All Electrofusion fittings are manufactured using virgin PE100 black polyethylene Water PN16 (All stated technical specifications depend on PE pipe welded to and any local pipeline pressure regulations)
Fusamatic pin 4.0mm (automatic method to ensure correct welding parameters are used) Rising pin fusion indicators allow for easy monitoring of the fusion process Manual welding parameters moulded into the body of the fitting
All electrofusion fittings are individually numbered for precise tracking Permanent batch number - clearly marked for quality control Barcode and QR code enables full traceability of each fitting back to raw materials and critical components Welding barcode compliant with ISO 13950 and traceability barcode compliant with ISO 12176-4

Available as electrofusion end caps，with excess flow valves
