PVC-U CONDUIT BEND (NEMA TC 2)
|
Spec(inch) |
Spec(mm) |
Nominal Pressure |
|
|
SCH40 |
SCH80 |
||
|
Thickness |
Thickness |
||
|
1/2 |
21.34 |
2.77 |
3.73 |
|
3/4 |
26.67 |
2.87 |
3.91 |
|
1 |
33.4 |
3.38 |
4.55 |
|
1 1/4 |
42.16 |
3.56 |
4.85 |
|
1 1/2 |
48.26 |
3.68 |
5.08 |
|
2 |
60.32 |
3.91 |
5.54 |
|
2 1/2 |
73.03 |
5.16 |
7.01 |
|
3 |
88.9 |
5.49 |
7.62 |
|
3 1/2 |
101.6 |
5.74 |
8.08 |
|
4 |
114.3 |
6.02 |
8.56 |
|
5 |
141.30 |
6.55 |
9.52 |
|
6 |
168.28 |
7.11 |
10.97 |
|
8 |
219.08 |
8.18 |
12.7 |
|
10 |
273.05 |
9.27 |
|
|
12 |
323.85 |
10.31 |
|
REHOME PVC-U Bend (Polyvinyl chloride) are of good quality, low cost, high safety and reliability. It has the advantages of beautiful appearance, light weight and easy bend, high strength, anti-aging, corrosion resistance, high fire resistance, good insulation and so on. It is used in the buildings and structures to protect and secure wire, cable and communication network.
|
ITEMS |
PVC-U BEND 90 Degree, PVC-U BEND 45 Degree |
|
MATERIAL |
POLYVINYL CHLORIDE |
|
PRESSURE RATING |
SCH40, SCH80 |
|
SIZE RANGE |
1/2” ~ 12” |
|
STANDARD |
ASTM NEMA TC 2 |
|
COLORS |
WHITE, GREY, ORANGE |
|
CONNECTION |
SOLVENT CEMENT JOINT |
