d: inside diameter
L: Total length
L1:Support thickness
a: Socket depth
|
Specifications |
d |
D |
L |
L1 |
a |
Pressure |
Weight(kg) |
|
F63 |
63 |
85 |
119 |
19.5 |
104 |
S2.5 |
0.35 |
|
F75 |
75 |
102 |
125.5 |
21 |
111 |
S2.5 |
0.55 |
|
F90 |
90 |
121 |
136 |
22 |
120 |
S2.5 |
0.75 |
|
F110 |
110 |
147 |
136 |
22 |
122 |
S2.5 |
1.05 |
|
F125 |
125 |
159 |
138 |
25 |
122 |
S3.2 |
1.15 |
|
F160 |
160 |
206 |
150 |
28 |
133 |
S3.2 |
1.95 |
|
F200 |
200 |
254 |
160.5 |
30 |
145.5 |
S3.2 |
3.15 |
|
F250 |
250 |
310 |
199 |
39 |
182 |
S3.2 |
5.6 |
|
F315 |
|
|
|
|
|
|
|
-
