16mm/20mm/25mm PVC conduit pipe - Grey

Home > Product > PVC Pipe And Fittings > Conduit -- IEC614 > Conduit Pipe > 16mm/20mm/25mm PVC conduit pipe - Grey

16mm/20mm/25mm PVC conduit pipe - Grey

This low-smoke, zero-halogen conduit system effectively prevents the spread of flames and emits no toxic or corrosive gases during combustion, thereby protecting precision instruments within the building from corrosion damage. In terms of physical properties, the product offers excellent weather resistance and maintains superior impact strength even at extreme low temperatures of -45°C.

Share This Product:

Applications
Details
Advantages
Specification
FLOWCHAT

(1) Wiring installation
(2) Public area cable layout
(3) Security and protection system
(4) Indoor cabling
(5) Underground cabling

Properties	Specification
Color selection	Red / Blue / Grey
Raw material	Halogen free thermoplastic
Temperature range	-45℃ to +150℃
Resistance to bending	Rigid
Ageing resistance	UV stabilized
IP ingress protection	Waterproof
Resistance to flame propagation	V0
Electrical characteristics	With electrical insulated characteristics
Resistance to insulation	>1000MΩ, 2000V~ no breakdown

(1) Corrosion Resistance
(2) Strong Softness
(3) High Flow Capacity
(4) Light-Weight
(5) Anti-aging
(6) Fire Resistant Properties

Type/mm	Min OD	Max OD	Wall T/mm
Ø20	19.7	20	1.8 - 2.1
Ø25	24.7	25	1.8 - 2.1
Ø32	31.7	32	2.1 - 2.4
Ø40	39.7	40	2.4 - 2.7
Ø50	49.7	50	2.8 - 3.1
Ø63	62.7	63	3.0 - 3.5
Ø65	75.2	75.5	3.0 - 3.5
Ø80	88.7	89.1	3.5 - 4.1
Ø100	114.1	114.5	4.5 - 5.2
Ø125	140	140.4	5.5 - 6.3
Ø150	160	160.5	6.3 - 7.1
